CHASING M2 Pro Max ROV Underwater Drone CM2PM

CHASING M2 PRO MAX

The CHASING M2 PRO MAX is a professional-grade underwater remotely operated vehicle (ROV) designed primarily for government and industrial use. It features eight vectored thrusters that enable smooth 360-degree omnidirectional movement. The ROV can reach speeds up to 3 knots, dive to depths of 200 meters (656 feet), and operate within a horizontal range of up to 400 meters (1312 feet).

This model utilizes a quick assembly and disassembly system, allowing users to attach or remove over 20 accessories — such as sonars, the CHASING USBL KIT, and water samplers — without any tools. It also boasts an integrated docking station with five ports, making it easy to install up to five accessories simultaneously. Powered by the second-generation C-MOTOR 2.0 anti-stuck motors, the ROV delivers 30% more power, improving its resistance to getting stuck underwater. Additionally, the optional second-generation shore-based power supply system (C-SPSS) offers a battery compartment with an upgraded 1500W output, enabling continuous full-power operation without interruptions.

The vehicle is equipped with two external floodlights that produce a combined 8000 lumens of light with a 150-degree beam angle. This design reduces glare caused by floating debris and brightly illuminates underwater details, with brightness adjustable from 0 to 100%. The floodlights can be folded or unfolded to suit various underwater environments.

Designed to simplify underwater tasks, the CHASING M2 PRO MAX is ideal for a wide range of industrial applications, including emergency underwater rescue, inspection of ship hulls and docks, aquaculture monitoring, water conservancy and hydropower inspections, scientific research, and offshore wind power facility assessments.

Convenient and Fast Assembly

Thanks to the quick accessory assembly system, mounting equipment on the ROV is efficient and tool-free. The slide-in mounting platform combined with the support rod minimizes the time and effort needed to attach or detach accessories.

Integrated Ports for Multiple Accessories

The ROV’s docking station integrates five ports, allowing users to connect multiple accessories simultaneously. It supports more than 20 CHASING and third-party devices, including:

• LASER Scaler

• Auxiliary Camera

• DISTANCE LOCK SONAR

• Imaging SONAR

• WaterLinked DVL

• Adapter Box

• USBL

• Grabber Arm 2

• Control Console

• Multiparameter Sonde

• 500ml Water Sampler

• C-SPSS

Versatile Applications

Its flexible accessory combinations enable it to meet the demands of many underwater tasks, such as:

• Search and rescue operations

• Hull and dock inspections

• Aquaculture monitoring

• Water conservancy and hydropower inspections

• Scientific exploration

• Offshore wind power inspections

Powerful Lighting

The two external floodlights provide a total of 8000 lumens with an optimal 150-degree beam angle, reducing visual interference from debris reflections. Their brightness is steplessly adjustable, and they can operate either folded or unfolded underwater to suit different working conditions.

Extended Operating Range

The M2 PRO MAX can dive as deep as 200 meters (656 feet) and operate within a horizontal radius of 400 meters (1312 feet). It also supports different tether cable lengths for broader operational flexibility.

High-Quality Imaging

Equipped with a 1/2.3” SONY CMOS sensor, the ROV captures 4K video and 12-megapixel photos with electronic image stabilization (EIS) to minimize shake and blur underwater.

• Supports 4K and 1080p video recording

• 12 MP photo resolution

• EIS for steady footage

• Removable Micro SD card (default 128GB, expandable up to 512GB)

Summary of CHASING M2 PRO MAX Key Features

• Industrial-grade underwater ROV

• Quick, tool-free assembly and disassembly

• Built-in docking station with 5 accessory ports

• Optional C-SPSS providing 1500W power for uninterrupted operation

• Two 8000-lumen floodlights with 150° beam angle and adjustable brightness

• Max diving depth of 200 meters (656 feet)

• Max operating radius of 400 meters (1312 feet)

• 4K and 1080p video capture

• 12 MP photography with SONY CMOS sensor

• Electronic Image Stabilization (EIS)

• Default 128GB Micro SD card (expandable to 512GB)
