Muse Pandora Galvo 1064nm Fiber Laser – AI 3D Scan & Autofocus (MUSEPG-20)
Muse Pandora Enclosed Fiber Laser Engraving & Marking Machine | 20W–50W | Class 2R Safety Enclosure
Safely engrave and mark metals, polymers, and composites with the Muse Pandora Enclosed Fiber Laser Engraving and Marking Machine — a precision-engineered solution for professional creators, manufacturers, and workshops that demand accuracy, safety, and speed.
Featuring a Class 2R enclosed design with a motorized safety door, the Muse Pandora allows secure operation while maintaining unmatched optical precision through its pulsed 1064 nm fiber laser system.
With RetinaEngrave v3.0 browser-based software, users can control every detail directly from Windows, macOS, or Linux — no downloads or internet connection required.
Key Features
-
Browser-Based RetinaEngrave v3.0 Software: Works seamlessly on Windows, Mac, and Linux for fast, intuitive control.
-
Class 2R Enclosure with Motorized Door: Fully enclosed system for safe operation with the 160 mm lens.
-
Removable Floor Panel: Enables engraving of oversized or irregularly shaped objects by expanding the working area.
-
Rotary Attachment (Optional): Allows engraving on cylindrical materials such as cups, tools, and rings.
-
Material Database: Preloaded settings for aluminum, stainless steel, black acrylic, lexan, leather, granite, and more.
-
7" LCD Touchscreen: Manage laser power, autofocus, and job progress directly from the control interface.
-
3D Camera-Powered Autofocus: Uses Intel RealSense™ technology for rapid, accurate focus adjustment and perfect multi-height engraving.
-
Solid-State 1064 nm Fiber Laser: Air-cooled, maintenance-free design with a 25,000+ hour lifespan and no consumable parts.
-
Closed-Loop Galvanometer Scanners: Achieve 10× finer detail and 100× faster marking compared to mechanical laser systems.
-
Power Options: Choose from 20 W, 30 W, or 50 W configurations to match your production needs.
Technical Specifications
| Category | Details |
|---|---|
| Engraving Area | 4" × 4" (100 mm × 100 mm) up to 12" × 12" (300 mm × 300 mm) |
| Machine Dimensions | 19" × 23.6" × 15.75" (483 mm × 600 mm × 400 mm) |
| Weight | 240 lbs (109 kg) |
| Z-Table Range | 0–13" (expandable to 40" with Z-table accessory) |
| Laser Classification | Class 2R (enclosed) or optional Class 4 (open configuration) |
| Laser Type | Pulsed 1064 nm Fiber Laser |
| Laser Power Options | 20 W / 30 W / 50 W |
| Focus Lens | 163 mm (standard) |
| Power Supply | AC 110 V native (220 V option available) |
| Gross Power | < 1000 W |
| Operation Modes | Precision Raster, Vector, or Combination |
| Motion Control | Galvanometer (X, Y) + Stepper Motor (Z) |
| Beam Speed & Detail | 100× faster marking; 10× smaller spot size than CO₂ lasers |
| Software | RetinaEngrave v3.0 |
| Compatibility | Windows, macOS, Linux |
| Browser Compatibility | Chrome (recommended), Safari, Firefox, Edge |
| File Import Formats | PDF, JPG, PNG, BMP, TIFF, SVG, DXF, DWG |
| Wireless Connectivity | 802.11 n |
Performance & Precision
Using a pulsed 1064 nm laser source, the Muse Pandora projects an ultra-fine beam through high-speed galvanometer mirrors, eliminating belts or pulleys.
This closed-loop scanning design ensures pinpoint precision for metal engraving, serial number marking, and fine-detail pattern work — 100× faster and 10× more detailed than standard CO₂ laser systems.
Ideal For
-
Industrial part marking and serial number engraving
-
Metal, polymer, and composite fabrication
-
Custom jewelry and branding applications
-
Makers, labs, and educational institutions seeking professional fiber laser capability
